HIGH SPEED CHECK WEIGHING

High Speed Check weighing Solution.

The industrial checkweigher is a significant part of any production line, allowing industry stakeholders to check and measure the weight of products. The high precision Checkweigher even removes products produced outside the set weight tolerance criterion. Our Checkweigher price is quite affordable and requires low maintenance costs.

The Dynamic Checkweigher provides end-consumers with comprehensive quality assurance. Our Checkweigher Solutions trims down product recalls and protects branding aspects of a manufacturer, which helps drive customer repeat purchases.

Benefits of our Check Weigher Machine

Our High speed check weighing machines make surely improved production tolerances that lead more final products to be produced from lower inventory and use of resources. We are one of the top Checkweigher manufacturers in India, and our online check weigher machines fit varied production set-ups.

Our High Precision Checkweighers are enabled to control packaged and unpackaged products in different industries. They can be integrated with most of the production lines, offer data storage functions and provides insights for analysis.

Product Highlights High Speed Check Weighing Machines.

• Designed Especially for Pharma, Food, Spices & Components manufacturer
• Statistical Data Report facility
• IP 54 Protection
• SS304 construction

Key Features of High Speed Check Weighing

• High visibility 10inch TFT screen with a graphic user interface
• Automatic weighing compensation and zero tracking
• Automatic measuring time adjustment
• Bag or case weighing up to 100g
• Easy integration in almost every production line
• Excellent accuracy, especially with flexible packaging
• 1,000,000pcs weight value for production statistics
• Data storage and data printout ready
• Variable belt speed control
• Designed for the control of packaged and unpackaged goods
• Statistics programs for evaluation

Technical Specifications

Technical Specifications
Model	GBCW -100g
Scale Division	0.05g
Weighing range	5~100g
Accuracy	±0.2g
Weighing speed	160pcs/min
Belt speed	5-90meter/min
Platform size	275x133mm
Height	830±50mm
Belt size	250x100mm
Belt material	PU (White)
Belt thickness	0.7mm
Tested object size	50-180×20-80×10-150mm
Display size	10 inch
Alarm light	3-color signal light
Alam horn	Optional
Holder/Frame material	304 stainless steel
Weigher platform material	304 stainless steel
Data storage	100 sets of parameters and 1 million weighing results
Communication	RS485 (Modbus RTU)/Modbus TCP/IP
Rejection mechanism	Swing ~ arm type, Flap type
Air pressure	0.4~0.6 MPa
Segment	3 levels
IP grade	IP54
