giri Hand Held Van Distribution Billing.

Description.

Our Distribution Hand-Held Van Distribution Billing Machine is a robust and user-friendly solution.

It boasts an integrated rechargeable battery and printer, making it a versatile choice for various billing and ticketing applications.

This innovative device has been specifically designed to address the challenges of situations where carrying a full set of equipment including a PC, printer, and UPS is impractical or inconvenient.

With this all-in-one solution, you can streamline your billing processes with ease and efficiency.

Features of Giri Van Distribution Billing.

• Transfer of stock to distribution vans.
• Field Billing after assessing the available stock at retailer premises.
• Tracking of damaged items.
• Processing of advance orders booked by retailers.
• Tracking of residual stock.
• Pending Payment Credit Limits.
• Transfer data to PC.

Reports.

• Sales reports.
• Order booking report.
• Stock report.
• Cancellation report.

Options of Giri Van Distribution Billing Machine.

• Smart card Reader – RF ID – 13.56 MHz Contact Less Smart Card Reader.
• In-Built GPRS Modem.



Sample distribution network.

A Distribution Centre having N number of Delivery Vans. Each van Distribution billing machine with unique identification number can be assigned with a particular Route and Set of customers.

Upto 1000 Customer details including Address ,Tin numbers can be stored.

Let us consider Vehicle No TN 007.

The Customers to be attended and the Stocks (eg:1000 numbers of The Hindu &250 Numbers of Business Line) to be delivered are uploaded in the billing machine by connecting the machine to a PC, within few seconds.

The materials are loaded in the Van. If any amount given to the van driver can also be entered in the machine.

The van reaches to the first Dealer Mylapore Paper Mart. He Purchases 100 Nos The Hindu papers and gives return of 5 old news papers. Also Purchases 50 Numbers of The Business Line.

All these can be loaded.

Specification of Van Distribution Billing.

Sl No.	Details	Distribution Biller GV100
1	No Of Items	1000
2	No of Creditors	1000
3	Delivery Locations	500
4	Catogories	50
5	Items In a bill	30
6	Date/Time	Battery Backed Real Time Clock.
7	Security	Multi-level Password & Data Encryption
8	Power	2200mAH Li-Ion, rechargeable battery
9	Recharging Time	Approx. 3 hours
10	Input Voltage	190 –240 V
11	Power Consumption	.8000 to 10000 lines printing per charge
12	Battery Life	Approx. 500 charge-recharge cycles
13	Charger	Portable, compact AC adaptor
14	Charging Source	AC
15	Display	128 * 64 Graphical LCD with backlight.
16	Keyboard	30 Key, Alphanumeric, Tactile, 10 million operable.
17	PC Interface	. USB Port.
18	Host System	Windows XP
19	Program Memory	512 KB Flash
20	Data Memory	MINIMUM 1 GB
21	Size	Approx. 24.5 x 4 x 10 cm at the printer portion and Approx. 24.5 x 4 x 6.9 cm at holding area
22	Weight	500 grams
23	Body	Moulded ABS / PC body.
24	Carrying Method	Shoulder Bag
25	Printer	24 Col. Dot Matrix
26	Paper Width	57 mm width (24 characters in a line)
27	Paper Roll Dimension	40 mm diameter. (about 12 – 15 meters)
28	Paper Loading	Manual
