crane scale with printer

DCS – CRANE SCALE WITH PRINTER

The CIBI DCS model crane scales with printer is the best solution for all your printing needs. Just the hand held device can be used to Record weight.
Hanging crane scale
The recorded Weight can further be processed to integrate with your ERP, Print on labels or papers, Stickers, in different formats. Like Barcodes QR codes etc.

These are tried and tested, widely used crane scales. They come with a rugged, aluminum ergonomic design. Its bright red 30 mm display provides better visibility at heights. It has a built-in rechargeable battery that provides a backup for up to 16 hours.It comes with a remote control, offering options such as Hold, Tare, Zero, and more.It is approved by the Weights and Measures Department of Legal Metrology. If you are looking for a simple crane scale, just opt for this. Best buy guaranteed.

DCS Crane Scale with Printer SalientFeatures

• Print on Lables , Papers etc.
• Can Print Barcode , QR code along with User Defined Fields
• Can Record weight and integrate with your ERP
• Cast aluminium housing for maximum protection
• Easy-to-read 30mm LED display
• Standard remote controller
• Battery operated with low battery indication
• On, Off, Zero, Tare and Hold-(Manual or Automatic) functions



Options

DCS Crane scale with printer  have the option to choose a Wireless Hand Held Indicator with a printout feature. It displays real-time weight on the screen, records weight data, and can transfer it to your PC or ERP system.The printout includes details such as Date, Time, Serial Number or Batch Number, accumulated weights, and a wide range of available reports.

Application

Industrial usage

Specification of DCS Crane Scale with Printer

MAKE	CIBI
Model	1DCS	2 DCW		3 DCW	5 DCW	10 DCW		15 DCW		20 DCW
Weighing Capacity	1000kg x 0.5kg	2000kg x 1kg		3000kg x 1 kg	5000kg x 2kg	10000kg X 5kg		15000kg X 5kg		20000kg X 10kg
Maximum Tare	Full Tare
Display Digit	LED (1.2 inch)
Operating Power	DC 6V
Power Source	AC 110/ 120/ 220/ 240V, 50/ 60Hz
Power Consumption	1W
Operating Temperature	-10℃ ~ +40℃
Dimensions (mm)	230(W) x 370(D) x 380(H)		230(W) x 370(D) x 474.5(H)				230(W) x 370(D) x 518.5(H)
Product Weight	15kg		17kg				20kg



Dimension

MODEL	A(mm)	B(mm)	C(mm)	H(mm)	N.W.(kg)
DCS-1	67	350	33	450	13.5
DCS-2	67	350	33	450	13.5
DCS-3	95	350	40	510	17
DCS-5	113	365	50	625	26
DCS-10	122	365	60	760	40
DCS-15	144	365	70	835	55
DCS-20	166	365	85	900	68
