weight controller c8

The C8 Indicator is a state-of-the-art weighing instrument designed for precision measurements and calibration tasks. It features advanced technology and user-friendly controls to ensure accurate and efficient weighing processes.

Features

giribrothers.in

◆3 inputs, 3 outputs (3 output relays inside) control
◆High precision A/D conversion with readability 1/30000
◆With 5 points nonlinearity amend
◆If change the former indicator, no need to re-calibrate, only to input parameter of former indicator
◆Embodies with automatic grarimetric filling instruments, catchweigher, alarm for max and min limitation and peak value preserving functions
◆Able to set fixed-value, pre-act value, Max-min limitation, and delay time freely based on different applications
◆1-2 materials available for plus/minus scale; external, self-testing, and free max and min modes are available for catchweigher
◆Standard RS-232/422/485 communication interface, baud rate and way of communication is optional
◆Standard scoreboard interface serial sending signal by 20mA current loop (constant current)
◆Precise simulate signal output with mode of 4-20mA/0-20mA/0-5V/0-10V optional, adjustable
◆Accumulative weight and times is able to be stored, check, delete, and with date-protection when power cut off
◆Able to connect with serial printer to print weighing record, accumulative amount or combined information, kg, t, g, lb is an optional print unit
◆Zero tracking, range for zero (automatic and manual) is free to be set
◆Strong anti-jamming and reliability
◆ESD protection performance: touch 6KV, air 8KV.
◆Able to recover from factory setting

weight controller c8

1. Key Features:
   • Explore the standout features of the Weight Controller C8, including any advanced functionalities, precision capabilities, or unique attributes that set it apart.
2. Specifications:
   • Provide a detailed breakdown of the technical specifications, such as load capacity, measurement resolution, accuracy, and any specific units of measurement supported.
3. User Interface:
   • Discuss the design and functionality of the user interface, including the type of display, controls, and any user-friendly features that enhance the operator’s experience.
4. Connectivity Options:
   • Explore the connectivity options available, such as communication ports (USB, RS-232, Ethernet) and compatibility with external devices or computer systems.
5. Applications:
   • Detail the intended applications of the Weight Controller C8. This could include its use in manufacturing, industrial processes, or any specific niche where precise weight control is crucial.
6. Industrial Integration:
   • Discuss how the Weight Controller C8 integrates into industrial processes, automation systems, or production lines. Explore any compatibility with other industrial equipment.
7. Calibration and Accuracy:
   • Explore the calibration mechanisms employed by the Weight Controller C8, highlighting its accuracy and precision in weight measurements.
8. Data Logging and Recording:
   • Discuss whether the Weight Controller C8 has features for data logging, recording measurement data, and generating reports for quality control or compliance purposes.
9. Durability and Construction:
   • Detail the build quality of the Weight Controller C8, including the materials used and any features that contribute to its durability in industrial environments.
10. Customization Options:
    • Explore whether the Weight Controller C8 offers customization options to meet specific industry requirements or user preferences.
11. Ease of Maintenance:
    • Discuss any features that simplify maintenance tasks, such as accessibility for cleaning, firmware updates, or replacing components.
12. Environmental Considerations:
    • Explore whether the Weight Controller C8 has features that make it suitable for specific environmental conditions, such as temperature resistance or protection against dust and moisture.
13. Safety Features:
    • Detail any safety features integrated into the Weight Controller C8, such as overload protection mechanisms or alarms for abnormal conditions.
14. User Manuals and Support:
    • Explore the availability and comprehensiveness of user manuals, documentation, and customer support services provided by the manufacturer.
15. User Testimonials and Reviews:
    • If available, consider looking into user testimonials or reviews to gain insights into the practical experiences of individuals or industries that have used the Weight Controller C8.

Specification

◆Accuracy class: III
◆AD conversion method: Σ-△ conversion technology
◆AD conversion bit: 24bitConversion speed: 80 times/s
◆Input signal range: -19mV～+19mV
◆Input sensitivity: ≥1uV/e
◆Nonlinearity: ≤0.01%F.S
◆Full spam temperature: ≤8PPM/ ℃
◆Load cell excitation: DC：5V；350mA
◆Numbers of load cell connection: 1~8 load cells 350Ω.
◆Method of load cell connection: 6 wire, auto compensation for long distance.
◆Display: 7-digit LED, height of bit 0.5 inch, 11 status lights.
◆Division: 1/2/5/10/20/50/100 optional
◆Clock: able to show real time and date
◆Keyboard: 5 soft-touch buttons
◆Scoreboard interface: adopts serial sending signal by 20mA current loop
◆Communication interface: optional serial communication RS232C/RS422/RS485 and baud rate 600-9600
◆Print interface: share the serial interface, able to connect with serial printer.
◆Replay output: capacity of AC: 220V, 0.5A
◆External input: on/off touch point (on/off controls in effect), able to connect controller such as proximity switch
◆Power supply: AC 110~230V，50/60Hz 1A
◆Temperature and humidity in application: 0～40℃；≤90％RH
◆Temperature for store and transportation: -20～50℃
